Misc. Equipment

CAM System with Bridgeport EZ Turn Software
Trinco Dry Blast Model 36
Trinco Model 24 Glass Bead Blaster
DoAll Band Saw 10 x 16
Work-A-Matic Saw 8 x 12
Roll In Band Saw 8 ½ x 8 ½
Roll In Band Saw 8 ½ x 12
Roll In Band Saw 8 ½ x 12
Wells Saw 10 x 16
Dake Saw
Cress Model C-2121 Heat Treat Furnace with Draw Furnace 7 x 10 x 20 Chamber
Lucifer Duel Chamber Furnace
Chamber 18 x 18 x 24

Grinding Department

Willis Surface Grinder
10 x 20
Kent Surface Grinder
16 x 42
Kent Surface Grinder
12 x 24
Kent Surface Grinder
10 x 20
Kent Surface Grinder
6 x 18
Reid Surface Grinder
6 x 18
Norton O.D. Grinder
10 x 36
Landis O.D. Grinder
6 x 32
Danobat I.D. Grinder
12” Swing
Sunnen Hone Fully Equipped up to 4”

Drill Press Equipment

Rockwell 17” Drill Press
Atlas 15” Drill Press
Wilton 20” Drill Press
DoAll 24” Drill Press
Welding Equipment
300 Amp Miller Wire Welder
250 Amp Arc Welder
250 Amp Arc/Tig Welder

Rapid Machine are Tool and Manufacturing Specialists utilizing leading edge technology since 1978.

EDM Department

Fanuc Alpha 1iCLS-S/AWF 12” Wire EDM
Maximum Work Piece Dimension 44 x 26 x 12
Travel:  X Axis 21.7  Y Axis 14.6  Z Axis 12

Fanuc Alpha C400iA Series Wire EDM
Maximum Work Piece Dimension 30.5x23.6x10
Travel: X Axis 14.6  Y Axis 10.6 Z Axis 10.2

Fanuc Alpha C600iA-16” Wire EDM
Maximum Work Piece Dimension 44 x 26 x 16
Travel:  X Axis 23 Y Axis 15  Z Axis 16

Fanuc Alpha C600iA-12” Wire EDM
Maximum Work Piece Dimension 44 x 26 x 16
Travel:  X Axis 23 Y Axis 15  Z Axis 16

Inspection Equipment

Starrett CMM
28 x 28 x 18

Superior Model  800 Inspection Unit

Superior Drill Sharpening Equipment
Superior Model 302 Drill Sharpening Machine

Superior Model 308 Subland/Step Angle Sharpener

Model 530 Drill Pointer/Splitter

Facilities List

Leading Edge Technology

Lathe Department

Romi C420 CNC
16.5” Swing 40” Center to Center

Bridgeport-Romi Centur CNC
20” Swing 40” Center to Center

Bridgeport EZ Path II CNC
20” Swing 60” Center to Center

Bridgeport EZ Path CNC
16” Swing 40” Center to Center

Summit CNC Lathe
24” Swing 60” Center to Center

Webb Engine Lathe
17 x 40

Webb Engine Lathe
15 x 32

Vertical CNC Machining Centers

Milltronics RH33
Travel:  X Axis 78 Y Axis 33  Z Axis 28

Milltronics RH20
Travel:  X Axis 40 Y Axis 20  Z Axis 24

Bridgeport 800-22 Vertical
Travel:  X Axis 31.5  Y Axis 20  Z Axis 19.5

Bridgeport 760-22 Vertical
Travel:  X Axis 31.5  Y Axis 20  Z Axis 19.5

Trak DPMSX5 Three Axis
Travel:  X Axis 40   Y Axis 20

Bridgeport Torq Cut 22 Vertical  Center
Travel:  X Axis 22 Y Axis 16 Z Axis 20

Milling Department

Atlas CNC Knee Mill with Acu-Rite Mill Power Control
Travel:  X Axis 32  Y Axis 15

3—PRM CNC Knee Mills with Acu-Rite Mill Power Control
Travel:  X Axis 30  Y Axis 12

3—Acer CNC Mill Power Control
Travel:  X Axis 30  Y Axis 12

2—Bridgeport EZ Trak 2 Axis CNC
Table 9 x 48

Devilieg Jig Mill 4H-60
